Built-In Web Server
The WebRelay Wireless works well as a stand-alone device that can be controlled and monitored using a standard web browser. It can be set up and configured using simple menus and drop-down lists.
Wireless Access Point
The WebRelay Wireless can be a self-contained wireless access point that requires no additional servers or ControlByWeb devices. In this mode the WebRelay Wireless provides live, real-time temperatures or input status directly to a user through web browsers or the CBW Mobile app (optional).
Setup is simple. There is no app to download, no subscription to buy, no software required, and no programming necessary for setup or use.
Logging
Record data such as sensor data and changes in I/O state. Both periodic and event-based logging are supported.
Email/Text Notifications
Record data such as sensor data and changes in I/O state. Both periodic and event-based logging are supported.
Peer-to-Peer (P2P) Communication
The WebRelay Wireless has the ability to remotely control relays located on other ControlByWeb devices.
- Built-in high current relay
- Optically-isolated digital input
- Up to 4 temperature sensors
- Wireless Wi-Fi 802.11 b/g/n
- Antenna included
- Transmission range up to 250ft
- Logging of the input, counter, temperature, humidity, relay state, and Vin
- BASIC script support for advanced flexibility
- Customizable web-based Control Page
- Send email alerts (up to 8 email addresses) based on user-defined conditions
- Supports encrypted email servers, such as Gmail
- Static or DHCP IP address configuration
- Real-Time clock with NTP server synchronization
- Automatic daylight savings and leap year adjustment
- No software required
- XML, Modbus/TCP and Remote Services
- Field updatable
- Removable terminal connectors for easy installation
- Rugged DIN-Rail/wall-mountable enclosure
- 5-Year Warranty
